Rigid C Type- RMC FITTINGS - O-Z/GEDNEY

In Stock
SR 0.00 SR 0.00 SR 0.00

The O-Z/GEDNEY rigid conduit outlet body is designed to provide easy access to conductors for pulling, splicing, maintenance, and future upgrades. It supports connections for straight runs, branch conduit lines, and 90° bends, making it ideal for complex conduit systems in both indoor and outdoor environments. Featuring tapered NPT threaded hubs, each unit comes complete under one catalog number and is ready to use out of the box. Constructed from die-cast, copper-free aluminum with an aluminum enamel finish, it includes a Type BS aluminum cover and a Type SGN neoprene gasket for reliable sealing. UL Listed (E-18095) and CSA Certified (LR-9795) for wet locations, it complies with industry standards including UL 514A, CSA C22.2 No. 18, Fed Spec A-A-50563, and NEMA FB-1 and FB-2.10, ensuring high performance and safety in demanding applications.

SKU:

OAQPLI5-1-2
  • Free Shipping apply to all orders over $100

    Free Shipping apply to all orders over $100

  • Guaranteed 100% Organic from natural farms

    Guaranteed 100% Organic from natural farms

  • 1 Day Returns if you change your mind

    1 Day Returns if you change your mind

  • Covid-19 Info: We keep delivering.

    Covid-19 Info: We keep delivering.

Applications
  • To provide access to conductors for pulling, splicing, maintenance and future changes/upgrades.
  • Allows connection of straight conduit runs, branch conduit runs and 90° bends.
Features
  • Tapered threaded hubs (NPT)
  • Packaged complete under one Catalog Number
  • Ready to use
Material/Finish
  • Conduit Body - Die-cast, Copper-free Aluminum with Aluminum Enamel
  • Cover - Type BS Aluminum
  • Gasket - Type SGN Neoprene
Third Party Certification & Standards
  • UL Listed: E-18095 (Suitable for wet locations)
  • CSA Certified: LR-9795 (Suitable for wet locations)
  • UL Standard 514A
  • CSA Standard C22.2 No. 18
  • Fed Spec A-A-50563
  • NEMA FB-1, FB-2.10
